Floor Box with 4 x 13A Sockets, Flush Mount, Cable Management

Specifications

• Type: flush mount floor box with sockets
• Power sockets: 4 x 13A, UK standard, fitted
• Data ports: 2 keystone compatible openings, data jacks not included
• Base: galvanized steel
• Lid: ABS plastic, click lock
• Colour: gray
• Size: 280 x 220 x 75 mm (length x width x height)
• Installation: flush mount, suitable for raised or concrete floors
• Load capacity: medium duty
• Use: indoor

About this floor box

This floor box puts four 13A sockets and two data openings into the floor, so power and network cables come up through one neat, flush outlet instead of trailing across the room. The lid closes over everything when you are not using it, and cables leave through slots in the lid.

Four 13A sockets, ready fitted

The sockets are the 13A UK standard type used in the UAE, so normal plugs fit. Two sockets sit on each side of the box, with the data openings between them.

Two openings for data

The centre section has two keystone compatible openings. They take keystone jacks such as network, HDMI, or USB, which you buy separately.

Flush lid with a click lock

The low profile lid sits level with the floor and closes with a click lock. Cable slots in the lid let leads exit while the lid is closed.

Galvanized steel base

The base is galvanized steel with several knockouts for conduit entry, and the lid is ABS plastic.

Where to use it

Offices, meeting tables, and conference rooms. Open plan workspaces and workstations. Showrooms, shops, and reception areas. Living rooms where you want sockets in the middle of the floor.

Common questions

How many sockets does it have? It has four 13A UK standard sockets, fitted, and two openings for data jacks.

Can I plug in a laptop charger and a network cable at the same time? Yes, the sockets take power plugs and the two keystone openings take network or other data jacks, so one box can serve a desk for power and data.

What data jacks fit in the openings? The openings are keystone compatible, so standard keystone jacks fit, such as network, HDMI, USB, and TV. Buy the jacks you need separately.

Can I close the lid with plugs in? Yes, cable slots in the lid let leads pass through while the lid is closed.

How deep does the floor need to be? The box is 75 mm high, so the floor needs a recess at least that deep, plus room for conduit entering through the knockouts.

Can I walk on it or roll a chair over it? It is rated medium duty and the lid sits flush with the floor. No load figure is given, so check with us before using it in a heavy traffic area or under loaded trolleys.

Is it waterproof? No water resistance rating is listed, so keep it out of wet areas and floors that are washed with water.

Can I fit it in a concrete floor? Yes, it is suitable for flush mounting in raised floors and concrete floors.

At Arowa Studio, we supply floor boxes, sockets, and lighting for offices, shops, and homes across the UAE, and we help you choose the right parts before you order. You can also visit our shop at Dragon Mart.

Before you order

• This box is wired to the mains and should be installed by a qualified electrician.
• Data jacks are not included.
• It is rated medium duty, so check with us for heavy traffic areas.
• For indoor use only.
